MG-105
Compact 6-Axis MEMS IMU Module
| Axis | 3-Axis (X, Y, Z) |
| Range | ±500°/s |
| Bias Stability (Allan) | ≤0.5°/h |
| Noise Density | < 0.01°/s/√Hz |
| Axis | 3-Axis (X, Y, Z) |
| Range | ±8g |
| Resolution | 16-bit |
| Communication | RS422 |
| Update Rate | 100-4000 Hz |
| Voltage | +5V±0.2 |
| Dimensions | 22.4×22.4×9 mm |
| Weight | ≤18g |
| Connector | JST ZH (4-pin) |
| Supply Voltage | +5V±0.2 |
| Power (Active) | 0.5W |
| Power (Sleep) | < 1μA |
| Operating Temp | -45°C to +80°C |
| Storage Temp | -45°C to +80°C |
| Shock | - |
The MG-105 is an ultra-compact 6-axis MEMS IMU integrating a 3-axis gyroscope and 3-axis accelerometer. Designed for consumer electronics applications like action camera stabilization and balance board systems, it offers excellent performance in a tiny 10×10×4mm package with low power consumption.
EIS stabilization
Motion detection
Flight control
